Model	SH274	SH276
Max Cutting Width	150mm(Thick about 110mm) 300mm(Thick about 40mm)	650mm(Thick about 50mm) 200mm(Thick about200mm)
Saw Blade Diameter	450MM	620MM
Motor Power	5.5KW	7.5KW
Weight	300KG	550KG
Overall Dimension	29009301100MM	425011501300MM

SH274 Timber Cutting Machine Timber Jump Saw Wood Cross Cut Machine Cut Off Saw

Automatic Wood Cut Off Saw Machine

Model	DZ-450	DZ-600
Saw Blade diameter	450mm*30mm	600mm*30mm
Feeding table length	2m/ 4m/ 6m	2m/ 4m/ 6m
Discharge table length	1200mm	1200mm
Cutting height	10-120mm	10-140mm
Cutting width	30- 200mm	30- 300mm
Cutting section thickness*width	Max. 120150mm,100200mm	Max.120300mm,140280mm
Feeding speed	5-30m/min	5-30m/min
Cutting speed	40pcs/min	45pcs/min
Cutter spindle rotation speed	3000rpm	3000rpm
Servo drive motor power	0.75kw	1kw
Cutting motor power	7.5kw/11HP	11kw/15HP
Total power	8.5kw	12.5kw
Pressing method	Cylinder, 0.5-0.7Mpa	Cylinder, 0.5-0.7Mpa
Cutting tolerance	In +/-1mm	In +/-1mm
Dust collection port	100mm*2pc	100mm*2pc
Electrical components	Schneider	Schneider
PLC Touching screen	Siemens	Siemens
Voltage	380v 50Hz 3 phase	380v 50Hz 3 phase

Pallet Foot Pier Cutting Saw Machine

Model	JD-1500
Cutting wood max. length	1500mm
Cutting Thickness	50-120mm
Cutting Width	60-200mm
Pallet foot pier size	30-200mm
Saw Diameter	400mm
Motor	7.5kw/3phase
Production capacity	1500-1800P/H
Weight	350kgs

Multi Blades Circular Saw for wood panels cutting off

cutting both ends of the panels in same length
cutting length is adjustable
with auto feeding
chain drive

Technical data:

Multi blades cutting off circular saw
Model	QT2000	QT3000	QT4000
Cutting height	100mm	100mm	100mm
Cutting width	2000mm	3000mm	4000mm
Circular blade diameter	300mm	300mm	300mm
Main motor power	3kw x2	3kw x3	3kw x4
weight	620kgs	820kgs	1020kgs
Overall size	3200x1800x1150mm	2200x1800x1150mm	4800x1800x1150mm

Photos:

Wood Slasher
Technical data
 	 			Technical Parameter 			DM1100 			DM1300 			DM1600 			DM1900 			DM2100 			DM2400
 			Guide Plate Length(MM) 			1100 			1300 			1600 			1900 			2100 			2400
 			Log Diameter(MM) 			900 			1100 			1300 			1600 			1900 			2200
 			Motor(KW) 			3 			3 			4 			4 			5.5 			5.5
 			Weight(KG) 			180 			190 			200 			220 			250 			280




Model	PE-40003	PE-50004	PE-60005
Cutting Length	600-4000mm	600-5000mm	600-6000mm
Cutting Thickness	10-120mm	10-120mm	10-120mm
Cutting Width	10-400mm	10-400mm	10-400mm
Saw Diameter	450mm	450mm	450mm
Blade Pieces	3P	4P	5P
Motor	7.5kW3 0.75kW2	7.5kW4 0.75kW2	7.5kW5 0.75kW2
Efficiency	100m³/8h	150m³/8h	200m³/8h
Weight	2000kg	2500kg	3000kg
